TC Series Cutting Plotter
Technical Specifications:
|
Model |
TC631-A/AF |
TC801-A/AF
|
TC1261-A/AF
|
|
Cutting Size |
630mm/2.07ft |
800mm/2.62ft |
1260mm/4.13ft |
|
Media Size |
710mm/2.33ft |
880mm/2.89ft |
1340mm/4.40ft |
|
Max.Cutting Speed |
800mm/s |
||
|
Cutting Pressure |
5-800g Digital adjustable |
||
|
LCD Display&Stand |
Yes |
Yes |
Yes |
|
Buffer capacity |
1Gb |
||
|
Resolution |
0.0254mm/step |
||
|
Offset |
0-1mm/m |
||
|
Origin Adjustable |
Yes |
||
|
Repeatability |
0.127mm |
||
|
Power |
AC220V(110V)±15%，<100W |
||
|
Language Format |
HP-GL,DM-PL |
||
|
Interface |
USB2.0&Serial U-disk（TC-AF/DC-AF） |
||
|
Drive |
Step Motor |
||
|
Princh Roller |
3pcs |
5pcs |
|
Specifications are subject to change without prior notice,all rights reserved.
Highlight Features:
1. USB 2.0 interface, support hot-swappable, and is equipped with serial port to support the long-distance data transmission.
2. 1Gb super-memory achieves a long time Offline cutting, meanwhile, the data storage can be achieved even blackout.
3. New adopted ARM processor and new driver module,system more powerful,driving more stable. higher speed, lower noise.
4. Digital force & speed adjustable, direct and steady.
5. Humane design, allows to adjust cutting force and speed while working.
6. High-precision "steel barbed" axis, higher accuracy.
7. Auto. memory of blade force & Speed, adjustable at any time, easy to use.
8. Emergency stop & stop to return at any time to monitor the cutting quality, easy to operate.
9. The product has the fuction of offline copy up to 99 copies, which helps to save time and working labor effectively.
10 .TC series can be compatible with CorelDRAW, and it can be output from CorelDRAW directly..
11. TC series has the real contour cut function optinal(TC-AA), full-automatic and easy to achieve contour cut without interference from other light sources, high resolution.
